CEMA C Equal Length Impact Idlers
Martin Sprocket & Gear
Impact Troughing Idlers are located at loading and transfer points. The rollers are equipped with rubber discs that cushion the impact and reduce costly belt damage. Impact idler frames are reinforced to reduce bending and withstand heavy material loads.
Item # |
Roller Diameter |
Troughing Angle |
Belt Width |
Replacement Roll NO. |
Manufacturer |
|---|---|---|---|---|---|
| C4-20TI-18 C4-20TI-18/Asset/Screenshot 2025-04-21 105452.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 18 in | Replacement Roll NO. N/A C4-TI-18 | Manufacturer N/A |
| C4-20TI-20 C4-20TI-20/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 20 in | Replacement Roll NO. N/A | Manufacturer N/A |
| C4-20TI-24 C4-20TI-24/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 24 in | Replacement Roll NO. N/A | Manufacturer N/A |
| C4-20TI-30 C4-20TI-30/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 30 in | Replacement Roll NO. N/A | Manufacturer N/A |
| C4-20TI-36 C4-20TI-36/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 36 in | Replacement Roll NO. N/A C4-TI-36 | Manufacturer N/A Martin Sprocket & Gear |
| C4-20TI-42 C4-20TI-42/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 42 in | Replacement Roll NO. N/A C4-TI-42 | Manufacturer N/A Martin Sprocket & Gear |
| C4-20TI-54 C4-20TI-54/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 54 in | Replacement Roll NO. N/A C4-TI-54 | Manufacturer N/A Martin Sprocket & Gear |
| C4-20TI-60 C4-20TI-60/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 4 in | Troughing Angle N/A 20 º | Belt Width N/A 60 in | Replacement Roll NO. N/A C4-TI-60 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-18 C5-20TI-18/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 18 in | Replacement Roll NO. N/A C5-TI-18 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-20 C5-20TI-20/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 20 in | Replacement Roll NO. N/A C5-TI-20 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-24 C5-20TI-24/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 24 in | Replacement Roll NO. N/A C5-TI-24 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-30 C5-20TI-30/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 30 in | Replacement Roll NO. N/A C5-TI-30 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-36 C5-20TI-36/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 36 in | Replacement Roll NO. N/A c5-ti-36 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-42 C5-20TI-42/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 42 in | Replacement Roll NO. N/A C5-TI-42 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-48 C5-20TI-48/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 48 in | Replacement Roll NO. N/A C5-TI-48 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-54 C5-20TI-54/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 54 in | Replacement Roll NO. N/A C4-T-54 | Manufacturer N/A Martin Sprocket & Gear |
| C5-20TI-60 C5-20TI-60/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 5 in | Troughing Angle N/A 20 º | Belt Width N/A 60 in | Replacement Roll NO. N/A C5-T-48- | Manufacturer N/A Martin Sprocket & Gear |
| C6-20TI-18 C6-20TI-18/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 6 in | Troughing Angle N/A 20 º | Belt Width N/A 18 in | Replacement Roll NO. N/A C6-TI-18 | Manufacturer N/A Martin Sprocket & Gear |
| C6-20TI-20 C6-20TI-20/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 6 in | Troughing Angle N/A 20 º | Belt Width N/A 20 in | Replacement Roll NO. N/A C6-TI-20 | Manufacturer N/A Martin Sprocket & Gear |
| C6-20TI-24 C6-20TI-24/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 6 in | Troughing Angle N/A 20 º | Belt Width N/A 24 in | Replacement Roll NO. N/A C6-TI-24 | Manufacturer N/A Martin Sprocket & Gear |
| C6-20TI-30 C6-20TI-30/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 6 in | Troughing Angle N/A 20 º | Belt Width N/A 30 in | Replacement Roll NO. N/A C6-TI-30 | Manufacturer N/A Martin Sprocket & Gear |
| C6-20TI-36 C6-20TI-36/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 6 in | Troughing Angle N/A 20 º | Belt Width N/A 36 in | Replacement Roll NO. N/A C6-TI-36 | Manufacturer N/A Martin Sprocket & Gear |
| C6-20TI-42 C6-20TI-42/Asset/Screenshot 2025-04-21 105452_2.png | Roller Diameter N/A 6 in | Troughing Angle N/A 20 º | Belt Width N/A 42 in | Replacement Roll NO. N/A C6-TI-42 | Manufacturer N/A Martin Sprocket & Gear |
